Full List of Ascott Optional Accessories

All Ascott test chambers are supplied complete and ready to run. Optional accessories may not therefore be necessary, but some may be considered desirable. Our team are happy to answer any questions you may have. Please contact us on +44 (0) 1827 318040 or email sales@ascott-analytical.com

Additional Chamber Fittings
Automation Accessories
Data Measurement & Recording
External Service Utilities
Optional Testing Facilities
Service & Spares

Optional Accessory	Ref.	Description
Kit for Renault ECC-1 / D17-2028 compliance	ACC01	A comprehensive kit of all necessary accessories to equip an Ascott chamber for compliance with Renault D17-2028 & RNES-G-005 which is commonly known as ECC-1. The kit includes ACC42 Wall Wash system, ACC47 Rapid Transition Time Heater Blower system, ACC82 Insulated Window Cover, ACC102 Salt Solution Consumption Indicator, ACC108 Fallout Measuring Kit and an increased Salt Fog Fallout system to achieve the required fallout The Ascott ECC1 Kit has been Renault as compliant. Not suitable for use with ACC46 So2 System. Note kit supplied as standard on Atmosfar Premium models
Salt Solution Resevoir (80 Litres)	ACC59/1	An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 460mm/18″ (w) x 620 mm/24″ (d) x 675mm/26″ (h)
Salt Solution Reservoir (115 Litres)	ACC59/5	A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h)
Salt Solution Resevoir (160 Litres)	ACC59/9	A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 840mm (w) x 500mm (d) x 790mm (h)
Air Compressor (large)	ACC04/2	A large free standing compressor, to provide a continuous supply of clean, dry and oil free compressed air, to enable the chamber to function without requiring connection to a local compressed air supply. Electrical supply: 220-240VAC single phase, 50Hz Output : 300 l/min displaced Free Air Delivery (FAD) @ 6 Bar : 179 l/min Max pressure: 8 Bar Air receiver: 59 litres Noise output: 74dB (A) measured at a distance of 1m
Guardian Angel System - Standard LED Version	ACC05/1	Modular traffic light alarm system fitted to the top of chambers, to provide visual notification of chamber status. Only available for Premium chambers (iP designations)
Guardian Angel System - LED Version, with USB Connectivity	ACC05/2	Modular traffic light alarm system fitted to the top of chambers, to provide visual notification of chamber status, with USB connectivity for remote monitoring. Only available for Premium chambers (iP designations)
Guardian Angel System - LED Version, with Ethernet Connectivity	ACC05/3	Modular traffic light alarm system fitted to the top of chambers, to provide visual notification of chamber status, with Ethernet connectivity for remote monitoring. Only available for Premium chambers (iP designations)
Guardian Angel System - USB add on only	ACC05/4	Retrofit add on for Guardian Angel, allows addition of USB connectivity for remote monitoring. Only available for Premium chambers (iP designations)
Guardian Angel System - Ethernet add on only	ACC05/5	Retrofit add on for Guardian Angel, allows addition of Ethernet connectivity for remote monitoring. Only available for Premium chambers (iP designations)
Water Deioniser System (Small)	ACC06/1	To provide water of suitable purity for topping up a salt spray/cyclic corrosion chamber air saturator, and for making up salt solution to be sprayed. Requires connection to a continuous mains water supply of maximum pressure 5.0 bar. This system comprises of a regenerable cylinder deioniser and an electronic conductivity indicator. Must be regenerated or replaced when exhausted.
Water Deioniser System (Medium)	ACC06/2	To provide water of suitable purity for topping up a salt spray/cyclic corrosion chamber air saturator, and for making up salt solution to be sprayed. Requires connection to a continuous mains water supply of maximum pressure 5.0 bar. This system comprises of a regenerable cylinder deioniser and an electronic conductivity indicator. Must be regenerated or replaced when exhausted.
Water Deioniser System (Large)	ACC06/3	To provide water of suitable purity for topping up a salt spray/cyclic corrosion chamber air saturator, and for making up salt solution to be sprayed. Requires connection to a continuous mains water supply of maximum pressure 5.0 bar. This system comprises of a regenerable cylinder deioniser and an electronic conductivity indicator. Must be regenerated or replaced when exhausted.
35mm Entry Port	ACC10/1	Sealable chamber entry port of 35mm (1.27″) through the chamber’s left hand wall to enable the connection of external monitoring/driving equipment. Note: not suitable for use with option ACC46.
110mm Entry Port	ACC10/2	Sealable chamber entry port of 110mm (4.33″) through the chamber’s left hand wall to enable the connection of external monitoring/driving equipment. Note: not suitable for use with option ACC46 or 120Ltr chambers
Hand-held salinity refractometer	ACC100	A salinity refractometer optimized to give a direct reading of percentage sodium chloride in the range 0 to 28%, with automatic temperature compensation. A single drop of the salt solution to be measured is placed on the viewing window, using the pipette supplied, and its salinity read against a high contrast scale, graduated in % sodium chloride, to give an accurate reading.
Salt Solution Consumption Sensor	ACC102	Electronic liquid flow sensor mounted inside the chamber and sensor situated in-line between the salt solution reservoir and the salt spray atomizer. The sensor measures the flow of salt solution from the reservoir to the atomizer. The output from the is displayed digitally at the chamber display as instantaneous consumption in ml per min and total consumption in ml. Designed for use where a high salt solution flow rate is required and where that flow rate should be displayed electronically, such as Renault D17 2028. This has collection rates that equate to 4-6ml/80cm²/hr. This system may not work effectively at collection rates below this. Only available for Premium chambers (iP designations).
Fallout Measuring Kit	ACC108	Comprises of 4 x 100ml measuring cylinders and 4 x 100mm funnels, for manually collecting and measuring salt spray fall-out inside a chamber, during salt spray testing.
Hand held pH meter	ACC11	Digital pH meter, for measuring the pH of salt solution fallout over range 0-14 pH with a resolution of 0.01 pH. Supplied complete with buffers for calibration.
Vertically Operating Canopy	ACC110	Special design of canopy to allow it to open to a vertical position to enable access from above (e.g. by hoist) for large and/or heavy test samples. *Exact part number dependent on chamber size.
12 Month Consumables Kit for Cyclic Chambers	ACC57/2	A kit of consumables sufficient for operating an Ascott Atmosfär, Kesternich, Cyclic or Salt Spray Premium chamber for up to 1 year. Includes Salt Filters for Atomiser, Silicone tubing, Humidity Prove Filter Cap with O Ring & Air Filter Note: A consumables spares kit is supplied as standard with every new chamber.
36 Month Servive & Spares Kit	ACC12/2	An initial kit of spare parts for servicing and maintaining a chamber for up to 3 years from its first use.
72 Month Service & Spares Kit	ACC12/3	A comprehensive kit for servicing and maintaining a chamber for up to 6 years from its first use, or its last service.
Data Logging Software	ACC121	This software allows logging of chamber variables and editing of chamber programs. It is uses a graphics based display which mimics and improves on the chamber interface. It can be loaded on Workstations or Laptops with Operating systems of Windows 10, Windows 8 Professional, Windows 7 Professional, Windows 2000 (SP4+), Windows XP Professional (SP3+). It also requires the following minimum hardware requirements – 1 GHz Processor minimum Processor, 256 MB RAM, video 1280 x 1024 (high colour 16 bit) and it is advised 2GB Hard Disk Space for data. The software communicates via an Ethernet network adaptor from chamber to PC / Laptop. The Workstation / Laptop also require a USB port to load the software and to accommodate the Dongle that is needed to run this software. Network must also be suitable as it will only work across a network on Class C subnet masks/ IP addresses – please liaise with your IT departments to confirm this or contact Ascott for further information. Only available for Premium chambers (iP designations).
Mesh Racking	ACC15	Mesh type racking with an aperture of 30mm for testing small component parts. Locates on either the upper or lower level supports provided as standard inside the chamber, and removable if required. This product is available in a variety of sizes to suit different capacity chambers.
Slotted Sample Racks	ACC16	Removable slotted type sample rack for testing panels/coupons. Each slot is 3mm/1/8” wide and angled at 15 degrees from vertical. Such racks are supplied as standard, unless otherwise specified. Wider slots and/or different angles are available on request. *Exact part number dependent on chamber size.
General Motors Test Plate Kit	ACC16/6	A kit of 10 specially designed Polycarbonate test plate holders and nylon fixings, as pictured, for mounting General Motors test plates in accordance with the requirements of GMW14872 – in an existing Ascott slotted sample rack, ref ACC16.
Variable Sample Racks	ACC14	Slotted sample racks for testing coupons on which the slot width and slot angle can be varied.
Rod Sample Racks	ACC17	Removable rod type sample rack for suspending small test samples hung beneath, or for supporting larger test samples placed on top of these racks. *Exact part number dependent on chamber size.
Spiked Sample Racks	ACC18	Removable spiked type sample rack for suspending test samples from the 10mm/0.4″ diameter x 55mm/2″ long spikes, equally spaced, and protruding from opposite sides. *Exact part number dependent on chamber size.
Reinforced False Floor	ACC19	Removable reinforced false floor, providing a horizontal platform over the chamber base for supporting large/heavy test samples. *Exact part number dependent on chamber size.
Waste Water Trough & Pump	ACC20	Where a floor level drain connection is unavailable this option provides a holding tank into which the chamber drain outlet is terminated. When full, waste water is automatically pumped to an existing remote drain/effluent tank, up to 10m/32ft horizontally & 3m/10ft vertically from the chamber. Note: not suitable for use with option ACC46.
Additional Atomisers	ACC25	Additional salt spray atomiser(s) and associated pump(s) to generate the higher fall-out rates (2.0 to 5.5ml/80cm²/hour) required during the salt spray phase of the VDA 233-102, Renault D17 2028 (ECC1), SAEJ 2334 and RNES-G-0005. Note: option ACC25 is not required if option ACC01 is ordered and is fitted as standard to AT Premium chambers
Interior Lighting	ACC26	Illuminates the chamber interior when a control panel push-button is pressed. *Exact part number dependent on chamber size.
Hand Held Temperature & Humidity Probe	ACC28	Precision hand-held thermo-hygrometer for independently checking the chamber temperature and humidity. Includes a special salt resistant measuring probe mounted on an extension cable. Range: -40 to +85°C & 0 to 100%RH. Requires any size entry port (see option ACC10) to access the chamber interior.
Water Fog Humidity Generation	ACC32	Provides high humidity conditions (95 -100% RH) by spraying water as a fog. Includes an additional reservoir for water, fog atomizer(s) and associated pumping equipment. *Exact part number dependent on chamber size.
Liquid Immersion	ACC34	Under programmed control, heated immersion liquid (usually salt water heated to a user adjustable temperature up to +50°C/+122°F) is automatically pumped from the holding tank into the chamber, immersing the test samples. The liquid is automatically returned to the holding tank at the end of the immersion period. Note: all versions of ACC34 require the chamber to be pre-equipped with option: ACC32/INT/**** *Exact part number dependent on chamber size.
Liquid Immersion Interface	ACC34/INT	Pre-equips a CCT chamber with everything needed to connect it to an ACC34 liquid immersion facility (available separately). The fitting of this interface enables the liquid immersion facility to be procured at the same time as the chamber, or later if required. Note: not suitable for use with option ACC46 or ACC10/2 *Exact part number dependent on chamber size.
Re-transmission of Temperature & Humidity	ACC36	Re-transmission of chamber temp & humidity as 2 x 0-10VDC signals via externally mounted socket. For remote data logging.
Wall wash	ACC42	A water spray system to automatically wash the internal walls of the chamber with water. Both wash time and duration are user programmable. Requires the chamber to be connected to a continuous pressurised water supply of suitable quality and temperature. Comprises of a water spray system to automatically wash the walls with water for a user adjustable number of minutes, at programmable points within a corrosion test cycle. This test is required for some automotive standards such as Renault D17 2028 or RNES-G-005 or ECC-1. It is also used when rapid cooling is required for JASO M 609 , CCT-1 and other automotive test standards. *Exact part number dependent on chamber size. Note this accessory is fitted as standard with ACC01 ECC1 Kit and all Atmosfar Premium Chambers
SO2 Gas Dosing	ACC46	Designed to meet the requirements of ASTM G85 annex A4, this optional accessory comprises of a chamber mounted dispersion tube, through which SO2 gas is introduced, at a user adjustable rate and for a programmable duration. *Exact part number dependent on chamber size. Only available for Premium chambers (iP designations). Notes. The provision of the SO2 gas cylinder and connector are the users responsibility and are not included as part of this option. The ACC46 is not suitable for use with options: ACC10, ACC34/INTERFACE, ACC92.
Temperature data logger	ACC50	A battery powered, chamber mounted data logger and temperature sensor. Continuously records the chamber air temperature (°C). Logs can be downloaded to a computer running appropriate software (provided).
Manual filling air saturator	ACC66	Enables the air saturator to be manually filled and periodically topped up with water by hand as an alternative to the automatic fill and top up provided as standard. Adds 75mm/3” to external chamber width.
80L Salt solution reservoir fitted with low level alarm	ACC59/3	An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 460mm (w) x 620 mm (d) x 675mm (h) Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Window insulated cover	ACC82	Comprises of an insulated cover, which is specially shaped to match the window aperture. This will reduce the amount of condensation that can form on the inside of the window during testing and will also improve thermal efficiency. *Exact part number dependent on chamber size.
Exhaust salt scrubber (without circulation Pump)	ACC92/2	Removes highly corrosive salt fog from the chamber exhaust where it is not convenient or possible to vent to the outside of the building. Removes salt through condensation and by spraying with water. Note: not suitable for use with option ACC46.
Exhaust salt scrubber (with circulation Pump)	ACC92/4	Removes highly corrosive salt fog from the chamber exhaust where it is not convenient or possible to vent to the outside of the building. Removes salt through condensation and by spraying with water. Note: not suitable for use with option ACC46.
Compressed air coupling	ACC94	A control panel mounted, quick release coupling to facilitate the connection of a third-party air pressure gauge (not supplied) for checking/calibrating the chamber’s own air pressure gauge.
80 Litre (21 US gal) capacity salt solution reservoir fitted with Air agitation	ACC59/2	An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 460mm (w) x 620 mm (d) x 675mm (h) Fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply.
Atomiser Airflow Optimiser	ACC106	An anemometer for measuring airflow and a mounting for this which positions it at a fixed distance from the end of the salt spray atomiser. This allows the airflow to be measured and if necessary adjusted. Consistent airflow at the atomiser can be a significant factor in obtaining good salt spray fall-out homogeneity, which is particularly important for some salt spray tests such as Renault ECC-1.
Blower Add on Accessory	ACC39	Addition of a blower fan assembly to assist with quick transitions of temperature/ humidity process values from a high to a lower level, such as GMW 14872. This is achieved by introducing ambient air from the local area in which the equipment is located by means of forced air blower and ball valve, no heat is provided by ACC39. If you required heated air please add ACC47 Note: A variation of ACC39 is already included in ACC80 and ACC01 accessories and is therefore not required. This is also fitted as standard to all Atmosfar Premium chambers
Blower Heater Add On Accessory	ACC47	Optional accessory to assist quick transitions of increasing and decreasing temperature and also decreasing humidity process values, such as JASO M609 / CCT-1. This is achieved by introducing ambient air from the local area in which the equipment is located by means of a forced air blower and ball valve. An air inlet heater is also fitted and automatically controlled if the chamber temperature needs to be increased, this enables enable a rapid transition from salt spray at 35°C to drying at 70°C within 30 minutes. Note: ACC47 is already fitted as standard with ACC01 & ACC80 accessories, and fitted to all Atmosfar Premium Chamber as standard.
80L Salt solution reservoir fitted with Air Agitation and low level alarm	ACC59/4	An 80 Litre (21 US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 460mm (w) x 620 mm (d) x 675mm (h) Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop. Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply.
Salt Solution Reservoir (115 Litres) fitted with Air Agitation	ACC59/6	A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h) Fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply.
Salt Solution Reservoir (115 Litres) fitted with Low Level Alarm	ACC59/7	A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h) Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Salt Solution Reservoir (115 Litres) fitted with Air Agitation & Low Level Alarm	ACC59/8	A 115 Litre (30US gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 560mm (w) x 620 mm (d) x 675mm (h) Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply. Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Salt Solution Reservoir (160 Litres) with Air Agitation	ACC59/10	A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 840mm (w) x 500mm (d) x 790mm (h) Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply.
Salt Solution Reservoir (160 Litres) with Low level Alarm	ACC59/11	A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 840mm (w) x 500mm (d) x 790mm (h) Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Salt Solution Reservoir (160 Litres) with Air Agitation and Low level Alarm	ACC59/12	A 160 Litre (42.2 US Gal) capacity salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 840mm (w) x 500mm (d) x 790mm (h) Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply. Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Salt Solution Reservoir (90 Litres)	ACC59/13	A 90 Litre (23US gal) capacity external salt solution reservoir & removable lid for ease of filling and cleaning. Graduated scale in litres. Can be mobile and mounted on castors for mobility when purchased with ACC59/15 Salt Solution Reservoir Dolly. External Dimensions: 540mm/21″ x 635mm /25″ width x height
Salt Solution Reservoir (73 Litres)	ACC59/14	A 73Litre (19 US gal) capacity External salt solution reservoir & lid for ease of filling and cleaning. Graduated scale in litres. Can be mobile and mounted on castors for mobility when purchased with ACC59/15 Salt Soution Reservoir Dolly. External Dimensions: 425mm Dia x 630mm (h)
Salt Solution Reservoir (73-90L) Dolly	ACC59/15	A Dolly for 73Litre (19 US gal) and 90L (23 US gal) External salt solution reservoir & lid for mobility.
Atmosfar 1300L Installation Kit	ACC58/12	A Handy Installation kit for Atmosfar 1300L Chambers to help you connect your equipment to your services and exhaust. Saves you time resourcing them locally and ensuring you get everything you will need. 3m of 3/4″ Drain Pipe inc couplers and elbows 3m of 4″ Exhaust Pipework inc Couplers and Elbows 6m of 13mm Braided hose inc Clips for Air and Water connections 1/2″ Hosetail Coupler-1/4″ Male-8mm to allow a push fitting. (Items can be purchased separately too upon request).
Atmosfar 2600L Installation Kit	ACC58/13	A handy Installation kit for Atmosfar 2600L Chambers to help you connect your equipment to your services and exhaust. Saves you time resourcing them locally and ensuring you get everything you will need. Comprising of: 3m of 3/4″ Drain Pipe inc couplers and elbows 3m of 4″ Exhaust Pipework inc Couplers and Elbows 6m of 13mm Braided hose inc Clips for Air and Water connections 1/2″ Hosetail Coupler-1/4″ Male-8mm to allow a push fitting. (Items can be purchased separately too upon request).
CR4 Grade Steel Corrosion Test Panels for ISO 9227 & VDA 233-102	ACC131	Ascott CR4 Test Panels are used to check the reproducibility and repeatability of the test results for Salt Spray or Cyclic Corrosion Test Chambers being being used to run ISO 9227 or VDA 233-102
Ultra Rapid Ramping Heater System to 80°C	ACC47/8 TO ACC47/15	A further upgrade to the heating system of the chamber allows the temperature to transition between 35°C and 70°C within 15minutes, required for Hyundai CCT-A / Hyundai CCT-B, and to also achieve a maximum operating temperature of 80°C, required for Volkswagen PV1200 & PV1209. Note: ACC47 is already fitted to all Atmosfar Premium Chamber as standard.
Two Button Canopy Control	ACC07	Two button canopy operation ensures that the user must stand to the side of the chamber and use both hands in order to operate the pneumatically actuated canopy
Test Plate to hold small items/fasteners	ACC43	A polycarbonate test plate holder pre-drilled with 7 holes (3 x 6mm, 2 x 5mm, 2 x 4mm) which are fitted with the nuts and bolts: 3 of them with fitted with an M6 x 25 nylon nut and bolt 2 of them with fitted with an M5 x 20 nylon nut and bolt 2 of them with fitted with an M4 x 25 nylon nut and bolt When loaded with samples the plate slots into the standard slotted sample racks (Ref ACC16) The plate can be used in different ways, if the nuts and bolts are removed the holes can be used to suspend samples directly (as long as the samples do not fall through the hole), or small samples with a through hole (nuts, washers etc.) can be suspended on the bolts.
Sikkens® Scratch Tool	ACC49	This scratching tool is specially designed to perform scribes on coated steel panels or test substrates prior to salt spray testing for example as described in ISO 9227 & ISO 12944-6 As standard, the scratch tool is supplied with 3 tungsten carbide cutting blades: 1 blade @ 0.5mm thick, the Daimler Chrysler version 1 blade @ 1mm thick, the original Sikkens® version 1 blade @ 2mm thick, requirement for 2018 update of ISO 12944-6 The blade is positioned by an adjustable guide block to assist cutting a straight line. The guide block can be easily adjusted using the Allen keys provided. The tool features a soft grip ergonomically designed handle for ease of use and is supplied in a carry case.
User programmable output signal	ACC78	This option enables the chamber user to have their own remote electrical equipment switched on/off at user programmable times, during a running test program. The output is provided via a voltage free change over contact (3A rated at 30VDC/250VAC) terminated at a chamber mounted 3-pin plug and socket for the user to wire to. There are 10 user settable time events, up to a maximum time of 9999 hours and 59 minutes. Maximum of 4 can be fitted to a chamber
Salt Solution Reservoir (227 Litres)	ACC59/16	A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 830mm x 640mm x 740mm
Salt Solution Reservoir (227 Litres) fitted with Air Agitation	ACC59/17	A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 830mm x 640mm x 740mm Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply.
Salt Solution Reservoir (227 Litres) fitted with Low Level Alarm	ACC59/18	A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 830mm x 640mm x 740mm Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Salt Solution Reservoir (227 Litres) fitted with Air Agitation & Low Level Alarm	ACC59/19	A 227 Litre (59.9 US Gal) salt solution reservoir, with a graduated scale in litres, a hinging lid for ease of filling and cleaning and mounted on castors for mobility. External Dimensions: 830mm x 640mm x 740mm Also fitted with Air Agitation to assist dissolving salt within a salt solution reservoir to create a thoroughly mixed salt solution. Regulated compressed air supplies a bubbling device that rests in the bottom of the reservoir. Note: requires connection to a compressed air supply. Fitted with Low Level Alarm that operates if the salt solution level falls below requirement for approximately 18 hours testing low level alarm at 1-2ml/hour fall-out rates. Sounds audible alarm and displays warning message. If reservoir is not refilled within 18 hours the running chamber program will automatically pause/stop.
Increased salt spray volume	ACC134	This accessory is designed in accordance with JSS 55555, which requires the quantity of salt solution sprayed per hour to be approx. 1% of the volume of the chamber, for example 4.5L p/h for a 450L chamber , 10L p/h for a 1000L Chamber 20L p/h for a 2000L Chamber and so on. This is achieved by fitting additional atomisers to the chamber.
Air Inlet Isolation Valve	ACC136	Isolation valve added to the inlet of the compressed air line. This allows for the Ascott chamber to be isolated from the incoming air , when the same airline is used for multiple pieces of other equipment.
Air Saturator Pressure Vent Solenoid valve	ACC137	Solenoid valve fitted to the air saturator to vent the air pressure; this allows the air saturator to automatically refill when the incoming water pressure is below the recommended 2.5 bar limit.
Analogue Air Pressure Gauge	ACC138	Analogue Air Pressure gauge, surface mounted on the front of the chamber, to see immediately the incoming air pressure. This is in addition to the digital air pressure gauge on the chambers control panel. If a chamber has more than 1 atomiser, the analogue gauge is supplied as standard. Note: ACC138 is already fitted as standard with ACC01, ACC134 & ACC25 accessories, and fitted to all Atmosfar Premium Chamber as standard.
Mass Loss Coupons for GMW14872 & GM9540P	ACC135	These panels are supplied in a Pack of 20, protectively wrapped to eliminate environmental contamination. With a 1/4″ / 6.35mm centre hole to allow for secure bracketing Heavy Oil Mass Loss Coupons that are fully compliant with the requirements of GMW14872 & GM9540P , Originally developed by General Motors these standards have gained popularity for corrosion tests within the automotive industry and have also become the preferred corrosion test of the US Navy.
